IMER · Rotor / Stator Pumps
Prestige 300
The Prestige 300 is a diesel-powered multi-purpose pump and spray machine with a built-in 6.3 cubic foot hydraulic mixer and onboard compressor for spraying.
Freight and sales tax are worked out for your ship-to address.
Technical specifications
| Model # | 1106433 |
|---|---|
| Engine Power | 24 HP |
| Compressor Flow Rate | 14 cf/m |
| Max Aggregate Size | 3/8 in |
| Hopper Capacity | 7 cu ft |
| Mixer Capacity | 6.3 cu ft |
| Dimensions w/l/h | 131.5 in x 55.5 in x 53 in |
| Weight | 1,653 lbs |
Manuals & sheets
Questions about the Prestige 300?
Specifications from the manufacturer. Prestige 300 at IMER USA
Overview
The Prestige 300 is a diesel-powered multi-purpose pump and spray machine with a built-in 6.3 cubic foot hydraulic mixer and onboard compressor for spraying. The military spec control panel integrates all these functions in one location, allowing operators to quickly and easily learn to operate the pump. Known for its versatility, the Prestige is designed to use different rotor/stator combinations for pumping a wide range of materials - including up to 3/8” aggregate with the optional L7 rotor / stator.
Standard equipment
- 24 HP diesel engine
- 14 CF/m compressor
- 2L6 screw pump
- 2 clean-out sponges
- High shear hydraulic mixer
- Variable speed hydraulic pump
- Programmable mixer timer
- Metal accessory box
- Tow package for highway use
Optional equipment
- 33' of 35mm hose — Part # 1107528
- 33' of 50mm hose — Part # 1107533
- Aqua Control Electronic Meter System — Part # 1107209
- Vibrating grate — Part # 1107036
- 164' remote control — Part # 1107086
- IM25L rotor/stator kit — Part # 1107149
- 60.12 Rotor/stator kit — Part # 1107090
- L7-1.5 Rotor/stator kit — Part # 1107660
- 50mm to 35mm material hose reducer — Part # 1106178
- Spray gun Step 120 — Part # 1107577
- 16' x 35mm male to 25mm male hose — Part # 1107074
- Pintle tow ring — Part # 1107161
- Shotcrete gun — Part # 1106250
- 5 Function radio remote — Part # 1107208
- Hydraulic power washer — Part # 1107171
- 5' overhead wand — Part # 1107549
See it work
